Hertz CS 200 S4

Size mm (in.) 200 (8)
Power Handling - Continuous W 150
Power Handling - Peak W 300
Impedance Ohm 4
Voice Coil Type single
No Filter Component SUBWOOFER
Voice Coil Ø 35 (1.38)
Magnet size D x d x h mm (in.) 120 x 50 x 28 (4.72 x 1.97 x 1.1)
Weight of one component kg (lb.) 2,87 (1.30)
Magnet High density flux ferrite
Cone Polyproyilene
Xmech mm (in.) 11,5 (0.45)

D mm 172
Xmax mm 9
Re Ohm 3,3
Fs Hz 40
Le mH 1,7
Vas I 13,7
Mms g 76,8
Cms mm/N 0,21
BL T*m 10,6
Qts 0,52
Qes 0,58
Qms 5
Spl dB 84
